TECHNICAL DATA 23
151
23.9 Chassis tightening torques
Nut, valve ISO 10V2 12 Nm (8.9 lbf ft)
Loctite
®
2701™
Remaining screws, chassis EJOTPT
®
K45x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, tail light EJOT DELTA PT
®
45x12‑Z 1.5 Nm (1.11 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
Remaining screws, chassis M4 3 Nm (2.2 lbf ft)
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw for throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, air filter box M5 3 Nm (2.2 lbf ft)
Screw, brake fluid reservoir for rear
brake
M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, cable on starter motor M5 3 Nm (2.2 lbf ft)
Screw, combination instrument M5 4 Nm (3 lbf ft)
Screw, combination switch, left M5 2 Nm (1.5 lbf ft)
Screw, combination switch, right M5 5 Nm (3.7 lbf ft)
Screw, engine sprocket cover M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, foot brake lever stub M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, fork protector M5x12 5 Nm (3.7 lbf ft)
Screw, fork protector M5x17 5 Nm (3.7 lbf ft)
Screw, heat guard M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, license plate holder M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, side stand sensor M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, trim M5 3 Nm (2.2 lbf ft)
Spoke nipple M5 5 Nm (3.7 lbf ft)
Nut, hand brake lever M6 Attach torque to nut.
10 Nm (7.4 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6LH 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw activated carbon filter on
retaining bracket
M6 8 Nm (5.9 lbf ft)
Screw, 6-D sensor M6 5 Nm (3.7 lbf ft)
