Kubota K008-5 User Manual

Operation
W9215-8135-1 99
06/2021
Swivelling the swivel frame K008-5
 To turn anticlockwise, move the left control lever (1) to the left
(figure/ ).
 To turn clockwise, move the left control lever to the right
(figure/ ).
The turning operation takes place as shown in the figure.
No person is allowed to stand in the swivel area during
the movement.
Swivel carefully to avoid any contact of the front at-
tachments with adjacent objects.
1
STOP

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
