Kubota K008-5 User Manual

Operation
W9215-8135-1 93
06/2021
Overview of control lever functions
The figure shows, in connection with the following table, the func-
tions of the left and right control levers.
Operating the boom K008-5
 To raise the boom, pull the right control lever back (figure/ ).
 To lower the boom, push the right control lever forward
(figure/ ).
The boom moves as shown in the figure.
Control lever Movement
Right control lever 1 Lower boom
2 Raise boom
3 Bucket crowd
4 Bucket dump
Left control lever A Arm dump
B Arm crowd
C Swivel frame to the left
D Swivel frame to the right
Watch the boom during lowering, so that the boom or
the bucket teeth do not hit the dozer.
1

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
