Kubota K008-5 User Manual

Operation
W9215-8135-1 89
06/2021
Turning on the spot
 Move the drive levers in opposite directions. The tracks will turn
in opposite directions. The centre of the vehicle is its vertical
axis.
(A) Turning on the spot to the right.
Driving uphill and downhill
 When driving on gradients, raise the bucket approx. 200 to
400 mm (A) above the ground (see figure).
 When driving on gradients, let the bucket slide over the ground
if the terrain allows it.
Exercise extreme caution when driving up and down a
slope.
STOP

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
