Kubota K008-5 User Manual

112 W9215-8135-1
06/2021
Operation
Opening and closing the engine hood
 Open the padlock and stow it safely.
 Pull lever (1) up and tilt the engine hood (2) backward. The en-
gine hood will stay in the open position because of the mount-
ing.
 To close, pull up the lever (1) at the mounting (2), then flip the
engine hood forward until it snaps in.
 Secure the engine compartment cover with a padlock.
Risk of burns on hot components!
Surfaces can be hot and lead to burns.
Before opening the engine compartment cover:
- Stop the engine and remove the key.
- Do not touch hot parts, such as exhaust muffler, etc.
- Wait until the components have cooled down in order for it to be safe to work.
STOP
1
2
1
2

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
