Kubota K008-5 User Manual

Accessories
W9215-8135-1 163
06/2021
 Pull O-ring (6) from the nut to bearing eye (5).
 Remove bolts (2) and (3) from the bearing boreholes.
 Make sure not to lose the spacers (figure above/8).
 Start the engine and raise the arm and/or the boom slightly until
the bucket is exposed.
 If a new bucket is not to be attached right away, insert the
O-rings, bolts and spacers into the bearing boreholes and se
-
cure them from being lost with the safety pins.
Attaching the bucket
 Ensure that the components indicated below are free of dirt and
dust.
 Ensure that an O-ring (6) is attached to each bearing eye (5).
 Check the O-rings and dust protection seals (7) for damage, re-
place them if necessary.
8
6
5
7
3
1
2
4
8
6
5
7

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
