Kubota K008-5 User Manual

96 W9215-8135-1
06/2021
Operation
Operating the arm U10-5
 To dump the arm, push the left control (1) lever forward (fig-
ure/ ).
 To crowd the arm, pull the left control lever back (figure/ ).
The arm moves as shown in the figure.
1

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
