Kubota K008-5 User Manual

92 W9215-8135-1
06/2021
Operation
Note on using wider and deeper buckets
Operating the dozer
 To lift the dozer, pull the dozer control lever (1) back (figure/ ).
 To lower the dozer, push the dozer control lever (1) forward
(figure/ ).
The dozer moves as shown in the figure.
When using a wider or deeper bucket, take good care
when swinging or retracting the front attachments to
make sure that the bucket does not hit the swivel
frame.
When working with the dozer, operate both drive le-
vers with the left hand and the dozer control lever with
the right hand.
1
K008-5
1
U10-5

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
