Kubota K008-5 User Manual

110 W9215-8135-1
06/2021
Operation
Replacing the fuses
 Open the cover of the step (K008-5).
 Open the door of the front control box rear cover (U10-5).
 Open the fuse box (1) and replace the blown fuse.
The fuse layout is shown in the next section.
Blown fuses may only be replaced with fuses of the same type and same rating.
The bypassing of fuses, for example with a wire, is not allowed.
If the malfunction cannot be remedied by replacing the fuse, or if the fuse blows again when starting,
contact skilled personnel.
The spare fuses are positioned in the fuse box (1).
1
K008-5
1
U10-5

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
