Kubota K008-5 User Manual

30 W9215-8135-1
06/2021
Safety rules
Locking the swivel frame
The swivel frame lock (1) serves to secure the swivel frame against
unintentional rotations, e.g. during transport.
If the swivel frame lock (1) is in the lower position, the swivel frame
and track frame are locked together.
Engine emergency stop
The engine turns off when the starter switch (2) is switched to the
STOP position.
If the engine cannot be turned off, please operate the engine emer-
gency stop knob in order to turn off the engine.
To stop the engine:
 Pull the knob (1) until the engine stops.
After the engine has stopped, push in the knob.
Before locking the swivel frame, the swivel frame and
track frame must be aligned parallel to one another.
1
2
1

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
