Safety rules
W9215-8135-1 29
06/2021
Safety devices
Before starting the machine, all safety devices must be installed properly and operational. Manipulating the safety
devices is prohibited.
Protective devices may only be removed once
 the excavator is standing still and the engine is stopped
 and secured against restarting (starter switch in STOP position and key removed).
Locking the controls
Locking the control lever K008-5
If the control lever lock (1) is located in the upper position, then the
hydraulic functions of the following controls will be locked:
 To release the control lever, place the control lever lock into the lower position.
Locking the control lever U10-5
If the left or the right control console (2) is raised completely with the
control lever lock (1), then the hydraulic functions of the following
controls will be locked:
 To unlock the hydraulic functions, lower the control console
completely using the control lever lock.
Function K008-5
Drive lever 
Right control lever 
Left control lever 
Make sure that all controls are in the neutral position
and that the control levers and the drive levers are
locked.
The hydraulic functions for setting the track width, op-
erating the dozer, swinging the boom and operating
the auxiliary port are not locked by the control lever
lock and can be activated.
Function U10-5
Auxiliary port pedal 
Boom swing pedal 
Drive lever 
Dozer control lever 
Right control lever 
Left control lever 
1
1
STOP
STOP
1
2

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
