Kubota K008-5 User Manual

62 W9215-8135-1
06/2021
Assembly and functions
Engine compartment
The engine compartment (see figure below) is located at the rear of the swivel frame below the operator's seat. It
is covered by a lockable engine hood.
2
1
4
5 6 7
8
11
9
10
12
13
14
15
161718
3
1. Radiator
2. Coolant expansion reservoir
3. Fuse box
4. Cock
5. Fuel filter with water separator
6. Battery
7. Engine hood lock
8. Hydraulic oil tank cap
9. Hydraulic oil tank
10. Preliminary fuel filter
11. Air filter
12. Exhaust silencer
13. Fuel reservoir
14. Engine
15. Oil filter cap
16. Oil dip stick
17. Oil filter
18. Alternator

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
