Kubota K008-5 User Manual

Assembly and functions
W9215-8135-1 53
06/2021
Control console U10-5
The control console (see figure) includes the following components:
1. Left control lever
2. Left drive lever
3. Right drive lever
4. Right control lever
5. Horn switch
6. Dozer control lever
7. Starter Switch
8. Boom swing pedal
9. Displays and indicators
10. Fast drive position pedal
11. Control lever lock (not shown)
12. Auxiliary port pedal
13. Throttle lever
The control console contains the following displays and indicators:
1. Fuel level indicator
2. Engine oil pressure indicator
3. Charge lamp
4. Time meter
5. Coolant temperature indicator
1
2 3 4 5
6
8
7
91012
13
123
5
4

Kubota K008-5 Specifications

General

Make	Kubota
Model	K008-5
Category	Compact Excavator
Bucket Capacity	0.022 m³
Max Dig Depth	1720 mm
Max Dump Height	2.43 m
Overall Length	2.75 m
Overall Width	700 mm
Fuel Tank Capacity	12 L
