3. SPECIFICATIONS
[1] HST MODEL
(To be continued)
Model L3540-II L4240-II L5240-II L5740-II
Engine
Model D1803-ME2-EU2 V2203-ME2-EU1 V2403-MTE3-EU2 V2403-MTE3-EU3
Type Indirect injection vertical, water-cooled, 4-cycle diesel
Number of cylinders 3 4
Total displacement 1.826 L (111.4 cu.in.) 2.197 L (134.1 cu.in.) 2.434 L (148.5 cu.in.)
Bore and stroke
87 × 102.4 mm
(3.4 × 4.0 in.)
87 × 92.4 mm
(3.4 × 3.6 in.)
87 × 102.4 mm (3.4 × 4.0 in.)
Net power*
25.9 kW
(35.2 HP)
31.7 kW
(43.1 HP)
38.7 kW
(52.6 HP)
41.5 kW
(56.4 HP)
PTO power*
(factory observe)
20.9 kW (28.4 HP)* /
2700 min
-1
(rpm)
26.1 kW (35.5 HP)* /
2700 min
-1
(rpm)
33.6 kW (45.6 HP) /
2600 min
-1
(rpm)
37.3 kW (50.7 HP) /
2700 min
-1
(rpm)
Maximum torque
101.7 N·m
(10.4 kgf·m,
75.0 lbf·ft)
139.7 N·m
(14.2 kgf·m,
103.0 lbf·ft)
180.6 N·m
(18.4 kgf·m, 133.2 lbf·ft)
Battery capacity 12 V, RC: 133 min, CCA: 582 A
Capacities
Fuel tank
44 L (11.6 U.S.gals,
9.68 Imp.gals)
50 L (13.2 U.S.gals,
11.0 Imp.gals)
54 L (14.3 U.S.gals, 11.9 Imp.gals)
Engine crankcase (with filter)
6.7 L
(7.1 U.S.qts
5.9 Imp.qts)
8.2 L
(8.7 U.S.qts
7.2 Imp.qts)
9.4 L
(9.9 U.S.qts, 8.3 Imp.qts)
Engine coolant
7.5 L
(7.9 U.S.qts, 6.6 Imp.qts)
8.2 L
(8.7 U.S.qts, 7.2 Imp.qts)
Transmission case
40 L
(10.6 U.S.gals,
8.80 Imp.gals)
39 L
(10.3 U.S.gals,
8.58 Imp.gals)
41 L
(10.8 U.S.gals, 9.02 Imp.gals)
Dimensions
Overall length
(without 3 point hitch)
3015 mm (118.7 in.) 3170 mm (124.8 in.) 3245 mm (127.8 in.)
Overall width
(min. tread)
1510 mm (59.5 in.) 1555 mm (61.2 in.) 1560 mm (61.4 in.)
Overall height 2230 mm (87.8 in.) 2250 mm (88.6 in.) 2375 mm (93.5 in.)
Wheel base 1805 mm (71.1 in.) 1895 mm (74.6 in.) 1915 mm (75.4 in.)
Min. ground clearance 345 mm (13.6 in.) 360 mm (14.2 in.) 405 mm (15.9 in.)
Tread
Front 1150 mm (45.3 in.) 1145 mm (45.1 in.) 1135 mm (44.7 in.)
Rear
1205 mm (47.4 in.),
1300 mm (51.2 in.),
1385 mm (54.5 in.)
1210 mm (47.6 in.),
1310 mm (51.6 in.),
1410 mm (55.5 in.)
1225 mm (48.2 in.),
1325 mm (52.2 in.)
