GENERAL
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
G-68
9. TIRES
[1] TIRE PRESSURE
WARNING
• Do not attempt to mount a tire on a rim. This should be
done by a qualified person with the proper equipment.
• Always maintain the correct tire pressure. Do not inflate
tires above the recommended pressure shown in the
operator's manual.
IMPORTANT
• Do not use tires other than those approved by KUBOTA.
 Inflation Pressure
Though the tire pressure is factory-set to the prescribed level, it
naturally drops slowly in the course of time. Thus, check it everyday
and inflate as necessary.
NOTE
• Maintain the maximum pressure in front tires, if using a
front loader or when equipped with a full load of front
weights.
9Y1211167GEG0101US0
Tire sizes Inflation Pressure
Front
11.2-24, 4PR 120 kPa (1.2 kgf/cm
2
, 17.4 psi)
12.4-24, 4PR 100 kPa (1.0 kgf/cm
2
, 14.5 psi)
13.6-24, 4PR 100 kPa (1.0 kgf/cm
2
, 14.5 psi)
13.6-26, 4PR 100 kPa (1.0 kgf/cm
2
, 14.5 psi)
13.6-28, 4PR 140 kPa (1.4 kgf/cm
2
, 20.3 psi)
355/80-D20, 4PR 100 kPa (1.0 kgf/cm
2
, 14.5 psi)
475/65-D20, 6PR 80 kPa (0.8 kgf/cm
2
, 12.0 psi)
Front
7-16, 4PR 180 kPa (1.8 kgf/cm
2
, 26.1 psi)
8-16, 4PR 160 kPa (1.6 kgf/cm
2
, 23.2 psi)
9.5-16, 4PR 220 kPa (2.2 kgf/cm
2
, 31.9 psi)
212/80-D15, 4PR 160 kPa (1.6 kgf/cm
2
, 23.2 psi)
29 × 12.00-15, 4PR 140 kPa (1.4 kgf/cm
2
, 20.3 psi)
(1) Ground (A) Insufficient
(B) Standard
(C) Excessive
KiSC issued 02, 2015 A
