ELECTRICAL SYSTEM
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
9-S14
2. SERVICING SPECIFICATIONS
9Y1211167ELS0005US0
Item Factory Specification Allowable Limit
GST Proportional Reducing Valve Resistance Approx. 8 to 9 Ω –
Shift Solenoid Valve Resistance Approx. 11 to 15 Ω –
Glow Plug Resistance Approx. 0.9 Ω –
Fuel Level Sensor
• Float at Upper-most Position
• Float at Lower-most Position
Resistance
Resistance
1.8 to 4.2 Ω
106.5 to 113.5 Ω
–
–
Coolant Temperature Sensor
•at −20 °C (−4 °F)
• at 40 °C (104 °F)
• at 100 °C (212 °F)
Resistance
Resistance
Resistance
Approx. 18.80 Ω
1.136 Ω
0.1553 Ω
–
–
–
Starter
• Commutator
•Mica
•Brush
• Brush Holder and Holder Support
O.D.
Under Cut
Length
Resistance
30.0 mm
1.181 in.
0.50 to 0.80 mm
0.0197 to 0.0315 in.
15.0 mm
0.591 in.
Infinity
29.0 mm
1.142 in.
0.20 mm
0.0079 in.
11.0 mm
0.433 in.
–
Alternator
• Stator
• Rotor
• Slip Ring
•Brush
No-load voltage
Resistance
Resistance
O.D.
Length
More than 14 V
Less than 1.0 Ω
2.9 Ω
14.4 mm
0.567 in.
10.5 mm
0.413 in.
–
–
–
12.8 mm
0.504 in.
8.4 mm
0.331 in.
