Kubota WSM L3540-II User Manual

CLUTCH
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
2-S3
2. SERVICING SPECIFICATIONS
9Y1211167CLS0002US0
Item Factory Specification Allowable Limit
Clutch Pedal Free travel 20 to 30 mm
0.78 to 1.18 in.
–
Clutch Disc Boss to Gear Shaft Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
Clutch Disc Disc Surface to
Rivet Top (Depth)
– 0.3 mm
0.01 in.
Diaphragm Spring Mutual Difference – 0.5 mm
0.02 in.
Pressure Plate Flatness – 0.2 mm
0.008 in.
