Kuka VisionTech 2.1 User Manual

20 / 109 Issued: 11.10.2013 Version: KST VisionTech 2.1 V1
KUKA.VisionTech 2.1
4.2 KUKA GigE switch
Basic data
Ethernet interface
Ambient condi-
tions
Standards and
guidelines
EN 61000-6-2 Electromagnetic compatibility (EMC) - Part 6-2:
Generic standards – Immunity for industrial envi-
ronments
EN 61000-6-4 Electromagnetic compatibility (EMC) - Part 6-4:
Generic standards – Emission standard for
industrial environments
Name Definition
Housing Metal
Protection classifica-
tion
IP 30
Dimensions 41 x 99.9 x 144.3 mm
Weight 580 g
Control voltage 12 … 36 V DC
Energy consumption approx. 7.5 W
MTBF > 450000 h @ 45°
Conformity CE, FCC Part 15, RoHS
Interface 1000base-T, 100base-TX, 10base-T
Standard IEEE 802.3 for 10base-T
IEEE 802.3u for 100base-TX and 100base-X
IEEE 802.3z for 1000base-X
IEEE 802.3ab for 1000base-T
IEEE 802.3x for flow control
IEEE 802.3at PoE specification (up to 30 watts
per port for PoE)
Ports 4x with PoE, 1x SFP, 1x without PoE
Packet size Up to 9 kB, supports jumbo frames
Auto-functions Auto-negotiation, auto-crossover
PoE Conforms to IEEE 802.3at
Protective function Against overload current
Power infeed Up to 30 watts per port
Storage -40 °C to +85 °C (233 K to 358 K)
Operation -40 °C to +60 °C (233 K to 333 K)
Air humidity 5 … 95% (no condensation)
Name Definition
2004/108/EC EMC Directive:
Directive 2004/108/EC of the European Parlia-
ment and of the Council of 15 December 2004
on the approximation of the laws of the Member
States relating to electromagnetic compatibility
and repealing Directive 89/336/EEC
EN 55022 Information technology equipment – Radio dis-
turbance characteristics – Limits and methods of
measurement
