54 / 109 Issued: 11.10.2013 Version: KST VisionTech 2.1 V1
KUKA.VisionTech 2.1
5. Send the generated file to VisionTech@kuka-roboter.de. KUKA Service
will use this to create a new licensing file and send it to you.
6. Click ..., select the received licensing file and confirm with OK.
7. Restart WorkVisual.
10.5.2.3 Activating an emergency license
Description It is possible to activate an emergency license. A total of 5 emergency licenses
are available. An emergency license is valid for 3 days. On expiry, emergency
licenses cannot be reactivated. For this reason, they should only be used in
an actual emergency.
Procedure 1. Select the menu sequence Editors > Option packages > VisionTech >
License configuration. The License configuration window is opened.
2. Click on Install emergency license.
3. Click on Activate emergency license.
4. Restart WorkVisual.
10.5.3 Creating a tool block file in WorkVisual
Procedure 1. Open the VisionTech plug-in:
Select the menu sequence Editors > Option packages > VisionTech
> Image processing task.
Alternatively: Click on the button.
2. Select the menu sequence Toolblock > New > 2D or 3D.
3. Select the menu sequence Image source > File... or Directory... and se-
lect the image(s) that were taken using the controller.
4. Click on the button. The image(s) are inserted next to the inputs under
InputImage.
5. Click on the button. Tools and templates are displayed.
(>>> 10.5.3.1 "Templates" Page 55)
6. Select the desired template or tool and drag it between the inputs and out-
puts.
7. Link the inputs and outputs, e.g.
InputImage under the inputs with InputIma-
ge
in the template. To do so, click on the input or output and drag it onto
the other input or output. The link is displayed by an arrow.
8. Double-click on the template and configure the desired pattern.
9. Click on the button and choose whether the tool should be saved com-
pletely or without images or results.
10. Select a directory and click on Save.
