DeviceNet
9 Technical data
9-1
L BA2175 EN 2.0
9 Technical data
9.1 General information
The internationally standardized CAN bus protocol, which had been developed for the European
Automobile Industry, is mainly characterized by:
• its resistance against interference and extreme temperatures
• short transfer times
• low expenditure for connection
These advantages have made CAN products interesting for other industries too.
The DeviceNet communication profile is based on CAN technology.
A DeviceNet network enables communication between control systems and industry components
suchas sensors (e.g. initiators)and actuators (e.g. electromagnetically actuated pneumatic valves),
frequency inverters and servos.
The units are directly connected to the network. This means reduced costs for installation,
commissioning, maintenance, tests and upgrading of the system.
The 2175 fieldbus module with the communication profile DeviceNet is a ’ONLY-SERVER’ module
of group 2.
9.2 Features
• Attachable module for the following Lenze controller series: 820X, 821X, 82X, 8200 vector,
93XX and 9300 servo PLC.
• The front DIP switch enables easy setting of
– Communication profile DeviceNet or CANopen
– Baud rates of 125, 250 and 500 kbit/s
– Node address (max. 63 participants)
• Bus extension up to max. 500m
• Topology: Line terminated at both ends (R = 120 Ohm)
• Easy connection because of pluggable screw terminals
