10 Installation
10-1
L BA2175 EN 2.0
10 Installation
10.1 Components of the fieldbus module
1
6 5
3
2
4
7
Pos. Designation Meaning Notes
S
t
t
f
t
h
OFF 2175 fie ldbus module is not supplied with voltage; controller or external voltage supply is switched off.
1
Status of the
controller
c
o
n
n
e
c
t
i
o
n
GREE
BLINKING 2175 fieldbus module is supplied with voltage but is not connected to the controller (controller is
switched off, in initialization or not available).
1
connec
t
i
on
(two-colour LED)
G
R
E
E
N
Constantly
ON
2175 fie ldbus module is s upplied with voltage and is connected to the controller.
OFF • No connection with the master
• Fieldbus module is not supplied with voltage
2
Connection status
GREE
N
BLINKING Dup_Mac_ID testing. Still no connection to the master .
2
C
o
n
n
e
c
t
i
o
n
s
t
a
t
u
s
(two-colour LED)
GREE
N
ON DeviceNet connection built up.
RED
BLINKING No communication because time limit exceeded
RED
ON Internal fault of the fieldbus module
3
Green and red drive
LEDs (drive)
Operating status of the following controllers: 82XX, 8200 vector, 93XX and servo PLC 9300
(see Operating Instructions for the controller)
4
Fixing screw
5
5-pole plug-in connector (see chapter 10.3.2)
6
Connection
PE shield cable
Only for 820X and 821X:
If necessary use an additional PE shield cable which avoids EMC-related communication interference
in especially noisy environments.
7
DIP switch For settings see chapter 11
