D9U001MCX-0101_03
94
13.15 Low Flat Position
In Low Flat Position the mattress support platform is rstly adjusted to at position without any lateral tilt and then lo-
wered to the minimum height.
To position Low Flat Position use:
► Lateral Tilt Foot Control
Fig. Low Flat Position Pedal
(Lateral Tilt Foot Control)
Lateral Tilt Foot Control:
► Press Low Flat Position Pedal and release it.
► Press and hold Low Flat Position Pedal once more until intended
position is reached.
NOTE: Lateral Tilt Foot Control is activated for 30s after this procedure.
13.16 Ergoframe
Ergoframe
®
is the kinematic system of Backrest and Thighrest Adjustment resulting in extension of the Mattress support platform in
the seat section. Ergoframe
®
enlarges the space for pelvic area during Auto-contour. Because of increasement of the space the force
applied results in decrease of the pressure that can cause pressure injuries in the pelvic area. Ergoframe maintains a stable ergo-
nomic position of the body and spine of the patient, thus limiting unwanted movement of the patient by moving down or up in beds.
Unied movement eliminates the patient‘s shift over the mattress and thus maintains a uniform position of the patient‘s body that is
not bound to the position of the bed parts.
