Technical Information
217
G 1xxx/G 2xxx
3. Release the C (clear) button when the display lights up.
4. Immediately press the C (clear) button 3 times; on the 3rd time, hold for
at least 4 seconds.
Acknowledgement indicator:
Successful accessing of the programming mode is indicated by the LEDs,
which are all off, and Service program, in the top line of the display.
The display always indicates three parameters at a time.
Use the cursor buttons to scroll through the display.
Options:
Function Programming Display
Check ID. no.
Select ID number. To
return to the main menu,
press OK.
The display shows the ID numbers
of the BAE (selection-display
electronic) and SLT (control-power
electronic).
Fault memory display
Select Fault memory. To
return to the main menu,
press OK.
The display shows the saved fault
codes. If multiple fault codes have
been registered, they are all shown.
Alternatively, the message No fault
is displayed. See Table 080-2 for a
list of fault codes.
Fault code deletion
Select Fault memory.
Select Delete fault
memory? with the cursor
buttons; confirm with OK.
In the display, the option Delete
fault memory? is shown along with
the saved fault codes.
Component test
Select Component.
Components V01 - V17
are activated via the
cursor buttons. To return
to the main menu, press C
(clear).
The display lists the available
components and mini-programs
with wiring diagram abbreviations.
The relevant test program starts
after 2 s (see Section 080-2.2).
Operating hours check
Select Operating hours
with the cursor buttons. To
return to the main menu,
press OK.
The display shows the number
of operating hours.
LED test
Select Operation. Select
B01: LED test. To return
to the main menu, press
C (Clear).
All LEDs and the display light up.
Buzzer test
Select Operation. Select
B02: Buzzer test. To
return to the main menu,
press C (Clear).
Buzzer on.
Table 080-40: Service Mode Summary, G 2630/G 2670
