Miele INSPIRA G 2140 Technical Information

Technical Information
46
G 1xxx/G 2xxx
Figure 010-3: Opening the Hinge Bracket
7. Disconnect the ground connection.
8. Remove the cable clip from its guide.
Warning!
Machines with salt container in door: As there is brine in the salt container,
have a means for collecting it on hand (bucket and cloth).
9. Disconnect the hoses to the brine valve Y60 (marked red) and the water
diverter (marked white). (Machines with salt container in door only.)
10. Unhook the door and lay it on a mat.
11. Remove the bottom door seal.
12. Remove the retaining screws (see Figure 010-4, Item 1).
Figure 010-4: Front Hinge Retaining Screw
13. Remove the hinge retaining screws in the door area (see Figure 010-5, Item 1).
