Technical Information

227

G 1xxx/G 2xxx

3 Fault Repair

3.1 Water Droplets on the Cutlery Tray

Symptom:

Excessive amount of water droplets on the cutlery tray after program has

finished.

Cause:

Water clings as a result of using a combination detergent.

Remedy:

Replace honeycomb-patterned inserts with inserts having a grid pattern.

Note:

The following inserts are available:

Insert 1/1: Mat. no. 06947010

Insert 2/3: Mat. no. 06929650

Insert 1/3: Mat. no. 06947000

Cause:

Honeycomb-patterned inserts.

Remedy:

Replace honeycomb-patterned inserts with inserts having a grid pattern.
