Technical Information

G 1xxx/G 2xxx

2.4.3 Reactivation

Figure 050-6: Reactivation

Water outlet to sump

EGS valve

Reactivation valve open

Connection to inlet valve

Note:

Since machine no. 79575776 (6/5/07), the two connections between the

water diverter and the salt container have each been fitted with 2 seals (O-

rings); see Figure 050-3, items 8 and 9.

Default Chapter2
