Programming
144
The assignment of valves to detergent dispensers is as follows:
Valves
Pre-wash compartment K1, W1
Main wash compartment K2, W2
Fabric softener compartment K3
Special application compartment K4
Direct water intake KD, WD
WRG inlet valve K6
The following valves are activated depending on programme blocks:
Programme structure Temperature range
Actual temperature
>Required
Actual temperature
=Required
Actual temperature
=Required
Pre-wash 1 KD, K1 WD, W1, KD, K1 WD, W1, KD, K1
Pre-wash 2-10 KD, K1 WD, KD, K1 WD, W1
Main wash 1 KD, K2 WD, W2, KD, K2 WD, W2, KD, K2
Main wash 1-10 (with pre-
wash)
KD, K2 KD, WD, W2, K2 WD, W2
Rinse 1 KD, K3 WD, KD, K3 WD, K3
Rinse 1 KD, K4 KD, WD, K4 WD, K4
Rinse 2 KD, K3 WD, KD, K3 WD, K3
Rinse 1 KD KD, WD WD
Rinse 2 KD, K4 KD, WD, K4 WD, K4
Rinse 3 KD, K3 WD, KD, K3 WD, K3
Rinse 1 KD KD, WD WD
Rinse 2 KD, K4 KD, WD, K4 WD, K4
Rinse 3-9 KD KD, WD WD
Rinse 10 KD, K3 KD, WD, K3 WD, K3
– User defined
– No
– 4 of 10 different water valves
11. Dispensing
method
Determines how the detergent is dispensed into the machine.
Choose from the following options:
– No
No dispensing
– Amount ml (millilitre)
– Concentration m/l (ml per litre)
Does not appear if Fill type is programmed to "Water level" or "Auto
load adjustment" in programme header.
– Concentration ml/kg (ml per wash load in kg)
