11-11
11
0 Special tools
Location Tool name and shape Part No. Application
7 Socket wrench MH061560 Installation of cylinder head and valve
assembly
9 Tappet extractor MH063329 Removal of tappet
03320
01984
◆ Service procedure
01948
6
6
Push rod deflection
If the measured value is higher than the limit, replace push rod 6.
03321
12410
• First loosen cylinder head bolts 4 in the numbered order as illustrated,
then remove them.
A
B
4
C
1
17
13
5
925
20
10
22 14 6
2
3
7
11
15
19
21
24 18
16
12
8
4
23
7
Cylinder head and valve assembly
[Removal]
• Before undoing cylinder head bolts 4, first loosen adjusting screw C of
rocker A that pushes down valve spring B.
7
