PISTON, CONNECTING ROD AND CYLINDER SLEEVE
● Disassembly sequence
1 Bolt
2 Lower connecting rod bearing
3 Connecting rod cap
4 Upper connecting rod bearing
5 Piston and connecting rod assembly
Õ P11-42
6 Cylinder sleeve
12702
*1 : Crankshaft Õ P11-52
*2 : Crankcase Õ P11-52
*3 : Oil pan ^ Gr 12
● Assembly sequence
Follow the disassembly sequence in reverse.
*3
-
*1
3
-
-
-Ê1
*2
