Mitsubishi FUSO FH 1997 User Manual

01-42
● Greasing Various Areas of Chassis
Carefully clean away all dust and dirt from the grease nipples, and use the specified type of grease. The areas to be
greased are shown in the following illustration.
LUBRICATION
27678
02246
02244 02245
1 Front spring pin front (left and right, 2 points)
2 Front spring pin rear (left and right, 4 points)
3 Rear spring pin front (left and right, 2 points)
4 Rear spring pin rear (left and right, 4 points)
5 Steering shaft
6 Kingpin bearing (left and right, 4 points)
7 Universal joint of propeller shaft
8 Slip joint of propeller shaft
9 Center bearing of propeller shaft
F Clutch fork shaft (left and right, 2 points)
5
1
2
6
F
9
3
7
4
8
02248
00360
00361
00362
02378
02453
Supply grease to the center
bearing until grease over-
flows from the escape
valve at the back of the
grease nipple.
02243
02247
