11-37
11
24 Connecting rod bearing
[Installation]
Install connecting rod bearings 2, 4 by matching lugs A to the connecting
rods.
CAUTION–
Be sure to distinguish between upper and lower connecting rod
bearings 2, 4. The upper bearing has oil opening B while the
lower bearing has no oil opening.
[Inspection]
CAUTION–
• Do not forcibly open or expand connecting rod bearings 2, 4.
• When either upper or lower connecting rod bearings 2, 4 needs
replacing, replace as a set.
03381
4
2
B
A
A
06358
(1) Expansion at free state
If the measured value is lower than the limit, replace connecting rod
bearings 2, 4.
(2) Clearance between connecting rod bearing and crankshaft
If the clearance between connecting rod bearing 2, 4 and crankshaft
*1 is lower than the limit, replace the faulty parts.
01997
12158
