11-27
11
03540
[Press-fitting]
• Press-fit idler gear bushing 13 from chamfered side B of idler gear 14
and align oil holes C of the idler gear and the bushing.
• After press-fitting, finish the fitting by bringing the clearance between
idler gear bushing 13 and the idler shaft to the standard value.
13
B
14
C
0
03536
G
Installation of thrust plate
A : Chamfered side
03538
03539
Idler gear bushing
[Removal]
A : Press
13
0
A
11
10
A
A
IK
Idler gear bushing and idler shaft
[Inspection]
If the clearance is higher than the limit, replace the faulty parts.
12637
H
Installation of idler gear assembly
Install idler gear assembly 12 by matching alignment marks “1”, “2”, “3”
on the gears that engage with those on the assembly.
*1 : Crankshaft gear
*2 : Camshaft gear
*3 : Air compressor gear
NOTE
When aligning each gear with its alignment mark, make sure that
pistons No.1, 6 are higher than top dead center.
12
*3
*1
*2
