Cylinder head gasket
[Removal]
CAUTION–
Be careful not to scratch the cylinder head or crankcase * when
you remove cylinder head gasket 8.
[Installation]
• Install cylinder head gasket 8 onto crankcase * in the direction as
illustrated.
CAUTION–
Be sure to measure the amount of protrusion whenever a piston
or connecting rod is replaced, since replacement changes the
amount of protrusion.
12411
“UP”
8
*
08790
03325
9
Removal of tappet
9*
Clearance between tappet and crankcase tappet hole
If the measured value is higher than the limit, replace the faulty parts.
*
0
9
9
