Mitsubishi FX3U Series Operation Manual

8 Debug in the positioning
8.2 Testing the Operation
80
FX Configurator-FP
Operation Manual
*1. For the user unit, refer to the following.
Refer to Section 5.1.
*2. For the servo motor rotation speed and the operation speed (converted pulse data), refer to the
following.
Refer to Section 5.1.3.
4 Click <REQ. present value change value> / <REQ. speed override>.
1. <REQ. present value change value>
FX Configurator-FP changes the operation speed to the specified value.
2. <REQ. speed override>
FX Configurator-FP changes the operation speed at the specified ratio.
Item Description
Monitor item
Displays present address, Operation speed present value, status information and Error
code
Present address
Displays the present address [Unit : User unit
*1
]
Operation speed present
value
Displays the operation speed present value [Unit : User unit
*1
]
READY/BUSY
Displays status information
• READY: ON
•BUSY: OFF
Table No. being
executed
Display X/Y-axis table No. in execution
This item is blank when using an operation pattern other than table operation
Error code
Displays error codes
Displays 0 with no error
Speed CHG Changes the speed to the specified one
Speed change
Sets the Operation speed
When setting the speed at or above the maximum speed, the speed is set to the
maximum speed.
Set the speed at or below the maximum rotation speed
*2
of servo motor
Setting range : 1 to Maximum speed[User unit]
*1
Set the value within 1 to 50,000,000Hz in the converted pulse data
<REQ. present value
change value>
Executes the speed change
Speed override Changes the operation speed override setting
Speed override
Sets the speed override ratio
Setting range : 1 to 30000 [0.1%]
<REQ. speed override> Executes the speed override change
<All axis stop> Stops all axis
<Stop> Stops the axis in operation test
<Close> Cancels the setting, and closes the dialog box
