10-ACCESSORIES

10-ACCESSORIES###_10_###

Optionalequipment

Grilleguard

Anoptionalpivotingfrontgrilleguardprovidesprotection

tothefrontofthetractor.Thegrilleguardiscompati-

blewithafrontendloaderoramaximumofthree27kg

(60lb)weightswithfrontweightbracket.

NHIL13CT00043AA1

10-1
