3-CONTROLSANDINSTRUMENTS
RIGHT-HANDSIDECONTROLS
Hydraulicpowerlift(HPL)
TheHPLlever(1)islocatedontheright-handcontrolpod.
Thelevercontrolsthepositionofthetwoliftarms.
DANGER
Crushinghazard!
Makesureareaisclearofallpersonsbefore
loweringequipment.
Failuretocomplywillresultindeathorserious
injury.
D0016A
Tolowertheliftarms,rstmakesurethedropratecon-
trolvalve(2)isopen,thenmovetheHPLleverforward.T o
raisetheliftarms,movetheleverrearward.Anadjustable
lowerstop(3)islocatedinthisquadrantforreturningthe
levertoapresetloweringpositionofthehitch.Anad-
justableupperHPLcontrolleverheightstop(4)prevents
thecontrolleverfromexceedingtheliftlimitandcausing
thetractorhydraulicsystemtogooverthereliefvalveset-
ting.
Thehydraulicliftsystemprovidesaccurate,smooth,and
instanthydraulicpowerforraisingavarietyofcompatible
equipmentwhenevertheengineisrunning.Thesystem's
positioncontrolfeaturemaintainstheselectedheightor
depthofthree-pointlinkageequipmentinrelationtothe
tractor.Whenthehydraulicliftcontrolleverismovedtoa
higherorlowersettinginthequadrant,thesystemrepo-
sitionstheequipmenttoahigherorlowerpositionand
maintainstheselectedposition.
NHIL12CT00681AA1
NHIL12CT00687AA2
Positioncontrol
Positioncontrolprovideseasy,accuratecontrolofthe
three-pointlinkageequipmentwhichoperatedabovethe
ground,suchassprayers,rakes,mowersetc.Italsopro-
videsuniformdepthwhenusingabladeorsimilarequip-
mentongroundlevel.
Whenoperatinginpositioncontrol,thereisadenitere-
lationshipbetweenthepositionofthecontrolleverinthe
quadrantandthepositionoftheequipment.Thelever
mustbemovedtochangethepositionoftheequipment
relativetothetractor.Thesystemwillautomaticallymain-
taintheequipmentintheselectedposition.
3-18

New Holland WORKMASTER 40 Specifications

General

Manufacturer	New Holland
Model	WORKMASTER 40
Category	Tractor
Engine Type	Diesel
Engine Power	40 HP
3-Point Hitch	Category I
Wheelbase	73.2 inches
Hydraulic System	Open Center
Fuel Capacity	9.2 gallons
Transmission	8x8 Synchro Shuttle
