New Holland WORKMASTER 40 User Manual

4-OPERATINGINSTRUCTIONS
Startingthetractorwithjumpercables
WARNING
Unexpectedmachinemovement!
Alwayssitintheoperator'sseattooperatethe
machine.DONOTbypassthekeystartswitch.
Suddenandunexpectedmachinemovement
ormachinerunawaycouldresult.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0464A
WARNING
Explosivegas!
Batteriesemitexplosivehydrogengasand
otherfumeswhilecharging.Ventilatethe
chargingarea.Keepthebatteryawayfrom
sparks,openames,andotherignition
sources.Neverchargeafrozenbattery.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0005A
WARNING
Explosionhazard!
Whenjump-startingthemachine,connect
anddisconnectthejumpercablesexactlyas
indicatedinthismanual.DONOTconnect
thejumpercablestothemachinebatteryter-
minals.Makesurenopersonsarenearthe
connectingpointsbeforestartingtheengine.
Starttheenginefromtheoperator’sseat.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0342A
NOTICE:Whenusingaauxiliarybatterytostarttheen-
gine,ensurethatthepolarityofthejumpercablesarecor-
rect,POSITIVEtoPOSITIVE,NEGATIVEtoNEGATIVE,
orthealternatororbatterymaybedamaged.
Ifyoumustusejumpercablestostartthetractor:
1.Shieldyoureyes.
2.Connecttheredendofthejumpercabletothepositive
(+)batteryterminal(1)onthetractorandconnectthe
otherredendtothepositive(+)batteryterminal(2)on
theauxiliarybattery.
3.Connecttheblackendofthejumpercabletotheneg-
ative(-)batteryterminal(3)ontheauxiliarybattery,
thenconnecttheotherblackendtoatractorframe
groundorengineground(4).Finally,startthetractor
byfollowingthesafestartingproceduresoutlinedun-
derSee4-12.
4.Whentheenginestartsallowtheenginetoidle,and
turnonallelectricalequipment(lights,etc.)Thiswill
helpprotectthealternatorfrompossibledamagedue
tochangesinloadwhendisconnectingthejumperca-
bles.
5.Disconnectthejumpercablesinreverseorder,dis-
connecttheblackendfromthetractorframeoren-
gineground(4)thendisconnecttheotherblackend
fromthenegative(-)batteryterminal(3)ontheauxil-
iarybattery.Disconnecttheredendfromthepositive
(+)batteryterminal(2)ontheauxiliarybattery,then
removetheotherredendfromthepositive(+)battery
terminal(1)onthetractorbattery.
201008781
4-15

New Holland WORKMASTER 40 Specifications

General

Manufacturer	New Holland
Model	WORKMASTER 40
Category	Tractor
Engine Type	Diesel
Engine Power	40 HP
3-Point Hitch	Category I
Wheelbase	73.2 inches
Hydraulic System	Open Center
Fuel Capacity	9.2 gallons
Transmission	8x8 Synchro Shuttle
