3-CONTROLSANDINSTRUMENTS
Clutchpedal
Thefootoperatedclutchpedal(1)controlsthesingle-
stageclutchandislocatedontheleft-handsideofthe
operatorsplatform.
NOTE:Theclutchpedalisonlyfoundongearmodeltrac-
tors.
Alwaysdepresstheclutchpedalfullywhenengagingor
disengagingthefront-wheeldrive.
Tostartthetractor,depresstheclutchpedalfullytoensure
asafestart-up.
930993481
Brakepedals
WARNING
Lossofcontrolhazard!
Unevenbrakeforceexistsonleft-handand
right-handbrakes.Toensureuniformbrake
applicationandmaximumstoppingability,al-
wayslocktheservicebrakepedalstogether
beforeroadtravel.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1188A
Therightbrakepedalcontrolsthebrakingactionofthe
rightrearwheel.Theleftbrakepedalcontrolsthebraking
actionoftheleftrearwheel.
ThefunctionofthebrakepedalsareidenticalfortheHST
andgearmodeltractorsexceptforthelocationoftheped-
als.Thebrakepedals(1)onaHSTmodeltractorarelo-
catedontheleft-handsideoftheoperatorsplatformand
thebrakepedals(2)onagearmodeltractorarelocated
ontheright-handsideoftheoperatorsplatform.
Depressbothpedalssimultaneouslytostopthetractor.
Toassistinmakingsharpturnsatslowspeed,depress
therightorleftbrakepedalasrequired.
Thebrakepedalconnectingpin(3)isusedtosecurethe
brakepedalstogether.Lockthepedalstogetherwhen-
everthetractorisoperatedathighspeedsorwhenthe
tractorisusedonthehighway.
NHIL12CT00691AA1
NHIL13CT00044AA2
3-8

New Holland WORKMASTER 40 Specifications

General

Manufacturer	New Holland
Model	WORKMASTER 40
Category	Tractor
Engine Type	Diesel
Engine Power	40 HP
3-Point Hitch	Category I
Wheelbase	73.2 inches
Hydraulic System	Open Center
Fuel Capacity	9.2 gallons
Transmission	8x8 Synchro Shuttle
