4-OPERATINGINSTRUCTIONS
Attachingthree-pointequipment
WARNING
Entanglementhazard!
Beforeattachingordetachingequipmentor
changingthePowerTake-Off(PTO)shaft:1)
Applytheparkingbrake.2)Moveallcontrols
toneutralandPTOcontrolknobtothedis-
engagedposition.3)Stoptheengineandre-
movethekey.4)WaitforthePTOshafttostop
turningbeforeleavingthecab.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0323A
NOTICE:Whenattachingmountedorsemimountedim-
plementtothethree-pointlinkage,ensurethatthereisad-
equateclearancebetweentheimplementandtherearof
thetractor.Theclearancesintheraisedpositionshould
becheckedbyraisingtheimplementcarefullywiththepo-
sitioncontrollever.Withtheimplementfullyraisedthere
mustbeatleast100mm(4in).Clearancebetweenthe
implementandthenearestpartofthetractor.
Mostimplementscanbeattachedtothetractorasfollows:
1.Positionthetractorsothatthelowerlinkhitchpoints
arelevelwithandslightlyaheadoftheimplementhitch
pins.Carefullybringthetractorrearwardstomatch
thetractorandimplementhitchpoints.Firstattachthe
left-handlowerlink,thenbyadjustingthelevelingbox,
attachtherightlowerlink.
2.Lengthenorshortenthetoplinkuntiltheimplement
mastpincanbeinsertedthroughthemastandupper
linkoftheimplement.
3.Whendetachingtheimplement,theprocedureisthe
reverseofattaching.Thefollowinghintswillmake
detachingeasierandsafer.
•
Alwaysparktheimplementonalevel,rmsurface.
•
Implementshouldbesupportedsothatitcannottipor
fallwhendetachedfromthetractor.
•
Alwaysrelieveallhydraulicpressureinanyremote
cylindersbeforedetaching.
4-5

New Holland WORKMASTER 40 Specifications

General

Manufacturer	New Holland
Model	WORKMASTER 40
Category	Tractor
Engine Type	Diesel
Engine Power	40 HP
3-Point Hitch	Category I
Wheelbase	73.2 inches
Hydraulic System	Open Center
Fuel Capacity	9.2 gallons
Transmission	8x8 Synchro Shuttle
