3-CONTROLSANDINSTRUMENTS
Rearremotehydraulicvalve(s)
WARNING
Escapinguid!
Donotconnectordisconnecthydraulicquick
couplerunderpressurizedconditions.Make
sureallhydraulicpressureisremovedfrom
thesystembeforeconnectingordisconnect-
inghydraulicquickcoupler.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0095B
Yourtractorcanbeequippedwithoneortwooptionalrear
remotehydraulicvalves.Thecontrollever(s)(1)and(2)
is/arelocatedrightsideoftheseat..
NOTE:Therearremotehydraulicvalvesareoptional
equipmentonHSTandgearmodeltractors.
NOTE:Rearremotehydraulicvalvekitsarecongured
ineithersinglespoolortwospool.Onceasinglespool
valveisinstalled,youCANNOTstackanothersinglespool
valve.Youmustpurchasethetwospoolvalvekit.
Tooperatethesingleortwospoolvalve,pulltheselected
controlleverrearwardtoextendthecylinderandpushthe
controlleverforwardtoretractthecylinder.Releasethe
controllevertostopthecylinderinanypositionbeforeitis
fullyextended.Theleverautomaticallyreturnstoneutral.
NOTE:Thevalvesdonothaveadetentedposition.
NHIL12CT00807AA1
NHIL12CT00819AA2
The#1(Green)setofcouplers(3)islocatedoutboardand
the#2(Blue)setofcouplers(4)islocatedinboard.
Therearremotevalvescomestandardwith12.7mm
(0.5in)femalequickcouplers.
NHIL12CT00771AA3
NHIL12CT00818AA4
3-19

New Holland WORKMASTER 40 Specifications

General

Manufacturer	New Holland
Model	WORKMASTER 40
Category	Tractor
Engine Type	Diesel
Engine Power	40 HP
3-Point Hitch	Category I
Wheelbase	73.2 inches
Hydraulic System	Open Center
Fuel Capacity	9.2 gallons
Transmission	8x8 Synchro Shuttle
