Appendix: 7210 SAS Boot Procedures
698
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Loading image ftp://*:*@192.254.173.17/usr/global/images/20.3/B1-1/7xxx/bcmiproc-
both.tim
Version B-20.3.B1-1, Wed Feb 12 15:32:56 IST 2020 by sasbuild in /home/sasbuild/
20.3B1/panos/main
text:(41388544-->175510640) + data:(6606080-->43372008)
Executing TiMOS image at 0x60100000
Step 20. After the 7210 SAS device boots up, the following login prompt is
displayed.
All rights reserved. All use subject to applicable license agreements.
Built on Wed Apr 20 22:44:35 IST 2011 by builder in /builder/3.0B5/R4/panos/main
Login:
Step 21. At the prompt, enter admin for the default username and password, and
log into the 7210 SAS device.
7.2.3 Procedure to Boot from the Network in Manual
Mode Using the OOB Ethernet Management Port
Perform the following steps to boot from the network using the OOB Ethernet
management port without using the auto-init mode.
Step 1. Power on the 7210 SAS device.
Step 2. Use the OOB Ethernet Management port to boot from the network.
Nokia 7xxx Boot ROM. Copyright 2000-2020 Nokia.
All rights reserved. All use is subject to applicable license agreements.
Build: X-20.3.B1-1 on Wed Feb 12 15:29:52 IST 2020 by sasbuild
Version: 0x38
Processor core is CN66xx
COLD boot on processor #1
?Preparing for jump to RAM...
Starting bootrom RAM code...
Boot rom version is v56
CPU #1 booted from working sector
CPU Control FPGA version is 0x3D
FPGA A version is 0x3D. FPGA B version is 0x3D. FPGA C version is 0x3D.
Restart type = 0x01
Note: The Sys LED is green when the device has successfully completed the boot process
and is running normally.
Note: This procedure is not supported for 7210 SAS platforms configured in the satellite
mode of operation. This procedure is supported on all 7210 SAS platforms that are
equipped with an OOB Ethernet management port.
