Appendix: 7210 SAS Boot Procedures
712
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Serial number : NS1734T0028
Manufacture date : 09182017
Manufacturing deviations : (Not Specified)
Manufacturing assembly number :
Administrative state : up
Operational state : up
Temperature : 48C
Temperature threshold : 85C
Software boot (rom) version : X-11.0.R4 on Wed Jul 10 13:44:15 IST 2019
by sasbuild
Software version : TiMOS-B-20.3.B1-3 both/hops Nokia SAS-Sx
64SFP+4QSFP28 7210 Copyright (c) 2000-2020
Nokia.
All rights reserved. All use subject to
applicable license agreements.
Built on Fri Mar 20 16:50:24 IST 2020 by
sasbuild in /home/sasbuild/20.3B1/panos/ma
Time of last boot : 2019/11/14 13:16:39
Current alarm state : alarm cleared
Base MAC address : d0:99:d5:a6:34:41
7.5 Procedure to Boot in the Standalone-VC Mode
Perform the following steps to boot the 7210 SAS device in the standalone-VC mode
of operation.
Step 1. Power on the 7210 SAS device.
Step 2. Use the OOB Ethernet management port to boot form the network.
A:NS1722T0086# admin reboot now
Resetting...OK
Nokia SAS-S 7210 Boot ROM. Copyright 2000-2018 Nokia.
All rights reserved. All use is subject to applicable license agreements.
Build: X-11.0.B1-6 on Thu Dec 6 15:22:31 IST 2018 by sasbuild
Version: 0x1F
DRAM test first stage
?Boot rom version is v31
CPLD Version: 0x0C
Board Serial Number is 'NS1722T0086'
DRAM test second stage
>>>Testing SDRAM from 0x0000000002200000 to 0x0000000080000000
>>>Testing SDRAM from 0xffffffffe0000000 to 0xffffffffe2000000
Note:
• This procedure is only supported on the 7210 SAS-S 1/10GE, 7210 SAS-Sx 1/10GE,
and their variants.
•See Provisioning and Booting Up the VC in Standalone Mode for more information.
