Parts
7-32
Part 1024496_06
2014 Nordson Corporation
Pump General Service
Part Description Quantity
1028304
Kit, service, pump, P4/P7/P10
—
940133 O-ring, Viton, 0.426 x 0.070 in. 2
940332 O-ring, Viton, 2.00 x 2.125 x 0.063 in. 2
1019515 O-ring, Viton, 0.50 x 0.75 x 0.125 in. 1
942111 O-ring, Viton, 0.812 x 0.062 x 0.125 in. 1
940181 O-ring, Viton, 0.739 x 0.70 in. 4
952100 Cup, U, Viton 1
954013 Backup ring, single,
7
/
16
x
9
/
16
2
163039 Cup, piston 2
273139 Seal, pump 1
986331 Retaining ring, internal, 100, push-on 1
1064157 NUT,HEX,LOCK,TORQUE,M6X1, DIN 980V,V3 1
982147 Screw, hex, cap, M6 x 120 4
982237 Screw, hex, cap, M6 x 35 4
983410 Washer, flat, M6 8
940172 O-ring, Viton, 0.676 x 0.070 1
‐ ‐ ‐ ‐ ‐ ‐ GREASE,HI−TEMP,.50OZ,SLUBE 884−.50 1
940261 O-ring, Viton, 1.25 x 1.375 x .063 1
1017849 Backup ring, PTFE, 1.273 x .045 thick 1
945037 O-ring, Viton, 1-inch tube 1
973543 Plug, O-ring,
7
/
16
-20 3
211228
Service kit, SP lubricating oil
—
Filter
Part Description Quantity
1028305
Filter, Saturn, 100-mesh
—
‐ ‐ ‐ ‐ ‐ ‐ Filter assembly, 100-mesh
945039 O-ring
Pneumatic Panel
Part Description Quantity
1028307
Kit, service, pneumatic panel assembly
—
‐ ‐ ‐ ‐ ‐ ‐ Pneumatic panel assembly 1
‐ ‐ ‐ ‐ ‐ ‐ Screw, mounting 2
