Nordson ProBlue P10 User Manual

400/480 Volt ProBlue Adhesive Melters
E-20
Part 1024496_06
 2014 Nordson Corporation
Parts
Transformer Assembly
Item Part Description Quantity Note
— 1039840 Base assembly, 1.5 kVA, transformer, ProBlue
— 1039841 Base assembly, 3.0 kVA, transformer, ProBlue
1 1040005  Cover, assembly, encl, transformer, ProBlue 1
4 1018819  Sub‐base, P7/P10 1
5
‐ ‐ ‐ ‐ ‐ ‐
 Screw, socket, M5 x 10 8
6 1039994  Base, transformer, ProBlue 1
7
‐ ‐ ‐ ‐ ‐ ‐
 Module assembly, power, distribution 1 B
8 1040056  Panel, terminal block, 3‐position, 750 V, 76 A 1
10
‐ ‐ ‐ ‐ ‐ ‐
 Screw, socket, M4 x 25 2
11
‐ ‐ ‐ ‐ ‐ ‐
 Nut, hex, M5 4/8 A
12
‐ ‐ ‐ ‐ ‐ ‐
 Washer, lock, spit, M5 14
13
‐ ‐ ‐ ‐ ‐ ‐
 Terminal lug, ground, 6–14 AWG 1
15 1040002  Shield assembly, water, transformer, ProBlue 1
17
‐ ‐ ‐ ‐ ‐ ‐
 Power transformer, automatic, 1.5 kVA 1/2 A/B
19
‐ ‐ ‐ ‐ ‐ ‐
 Washer, flat, regular, M5 4/8 A
22
‐ ‐ ‐ ‐ ‐ ‐
 Wire assembly, ground, 10 gauge 4
23
‐ ‐ ‐ ‐ ‐ ‐
 Lug, 45 degree, single, M5 x .032 2
24
‐ ‐ ‐ ‐ ‐ ‐
 Nut, hex, M5 6
25
‐ ‐ ‐ ‐ ‐ ‐
 Nut, hex, external tooth, M4 2
33
‐ ‐ ‐ ‐ ‐ ‐
 Shield, splash, terminal 1
NS 1040015  Harness assembly, transformer 1
NS 1039789  Plug, voltage, 400 V 1
NS 1039790  Plug, voltage, 480 V 1
NS 1040013  Plate, conduit 1
NOTE A: The first number in the quantity column is for 1.5 kVA transformer base assemblies, the second is for
3.0 kVA transformer base assemblies.
B: Refer to Service Kits.
NS: Not Shown
