400/480 Volt ProBlue Adhesive Melters
E-23
Part 1024496_06
2014 Nordson Corporation
400/480‐Volt Melter‐Specific Components
The following table lists melter components that are specific to 400/480 volt
melters. Refer to the ProBlue product manual, Section 7, Parts, for
information about melter components that are common to both standard and
400/480 volt melters.
Item Part Description Quantity Note
NS 1032085 Heating element, manifold, 480 V 1
NS 1037490 Weldment, tank, machined, P4, 480 V 1
NS 1037491 Weldment, tank, machined, P7, 480 V 1
NS 1037492 Weldment, tank, machined, P10, 480 V 1
NS 1033838 Harness, heater, transformer, P4, P7, P10 1
Service Kits
Part Description Quantity
1041660 Service kit, transformer, 400/480 V, ProBlue —
Power transformer, automatic, 1.5 kVA, 400/480 volt 1
1041662 Service kit, driver board, 400/480 volt, ProBlue —
Module assembly, power distribution 1
1041661 Service kit, fuse, 400/480 volt, ProBlue —
Fuse, 8A, fast‐acting, 600 V, CC‐REJ 2
Fuse, 5A, time‐delay, 600 V, CC‐REJ 4
Wiring Diagram
The wiring diagram on the next page is provided for your reference as
needed.
To Next Page
