Nordson ProBlue P10 User Manual

Parts
7-34
Part 1024496_06
 2014 Nordson Corporation
Main Circuit Board
Used Part Description Quantity
P4, P7 1028322
Kit, service, main PCA
—
P10 1028323
Kit, service, main PCA
—
‐ ‐ ‐ ‐ ‐ ‐  Mounting plate assembly, main PCA 1
Central Processor Unit (CPU)
Part Description Quantity
1028325
Kit, service, central processor unit
—
‐ ‐ ‐ ‐ ‐ ‐  PCA, display/CPU 1
‐ ‐ ‐ ‐ ‐ ‐  Stand-off, hex, M3 x 8 mm 6
‐ ‐ ‐ ‐ ‐ ‐  Washer, lock, M3 6
Operator's Panel
Used Part Description Quantity
P4, P7 1028326
Kit, service, operator’s panel/enclosure, P4/P7
—
P10 1028327
Kit, service, operator’s panel/enclosure, P10
—
‐ ‐ ‐ ‐ ‐ ‐  Panel assembly, front, electrical enclosure 1
Hose/Gun Module
Part Description Quantity
1028328
Kit, service, hose/gun module, P4/P7/P10
—
‐ ‐ ‐ ‐ ‐ ‐  Module assembly, power, removable 1
Main Circuit Board Fuses
Part Description Quantity
1028329
Kit, service, fuse, main circuit board, P4/P7/P10
—
‐ ‐ ‐ ‐ ‐ ‐  Fuse, 15.00, nontime-delay, 250 V 2
‐ ‐ ‐ ‐ ‐ ‐  Cover, fuse, 0.25 x 1.25 in. 2
‐ ‐ ‐ ‐ ‐ ‐  Fuse, time-lag, 2A, 5 x 20 mm, ceramic 2
‐ ‐ ‐ ‐ ‐ ‐  Cover, fuse, 5 x 20 mm 2
NOTE A: Refer to Table 6-2 for fuse types and locations.
