Installation
3-13
Part 1024496_06
2014 Nordson Corporation
Configuring the Electrical Service
ProBlue melters are shipped from the factory without an attached power
cable and without an electrical service type specified. To configure the melter
to function in your facility, you must connect a power cable and a
Nordson‐supplied voltage plug to the melter.
To connect a power cable to the melter
1. Select a power cable rated for the maximum amperage required by the
melter. Ensure that the power cable meets applicable electrical codes
and standards.
The maximum power draw for each ProBlue shipping configuration,
operating at 230 volt, in both 1‐phase and 3‐phase are listed in
Table 3‐2. The values presented in Table 3‐2 assume that each hose gun
module is being used at its maximum capacity of 2000 watts.
NOTE: Contact your Nordson representative for assistance in calculating
the melter's power draw for operating voltages other than 230 volts or for
assistance in calculating the exact power draw for specific hoses and
guns that are manufactured by Nordson Corporation.
Table 3‐2 Melter Power Requirement
Melter
Number of
Hose/Guns
1‐Phase Power
Draw (Amps)
3‐Phase Power
Without Neutral With Neutral
P4
2 17 15 9
4 26 23 17
P7
2 18 16 10
4 27 24 17
P10
2 18 16 10
4 27 24 17
6 36 31 18
