Technical Data
8-1
Part 1024496_06
2014 Nordson Corporation
Section 8
Technical Data
General Specifications
Item Data Note
Weight of empty melter
P4 42 kg (93 lb)
P7 43 kg (95 lb)
P10 46 kg (101 lb)
Weight of melter with full tank
P4 46 kg (101 lb)
P7 50 kg (110 lb)
P10 56 kg (123 lb)
Weight of 3.0 kva transformer (400/480 VAC
melters only)
25 kg (55 lb)
Weight of 1.5 kva transformer (400/480 VAC
melters only)
18 kg (40 lb)
Hose ports 4 to 6
A
Melt rate
P4 4.3 kg/hr (9.5 lb/hr)
P7 8.2 kg/hr (18 lb/hr)
P10 11 kg/hr (24 lb/hr)
Noise 64dB (A) at maximum pump speed
B
Workplace temperature -5 to 50C (23 to 122 F)
Throughput rate
P4 8.9 kg/hr (19.6 lb/hr)
P7 10.9 kg/hr (24 lb/hr)
P10 12.4 kg/hr (27 lb/hr)
Pump rate 32.7 kg/hr (72 lb/hr)
NOTE A: Depends on the melter’s configuration and whether optional hose/gun modules are installed.
B: The noise level is measured at a distance of 1 m (3.3 ft.) from the surface of the melter.
