Parts
7-35
Part 1024496_06
2014 Nordson Corporation
Hose/Gun Module Fuses
Part Description Quantity
1028331
Kit, service, fuse, hose/gun module, P4/P7/P10
—
‐ ‐ ‐ ‐ ‐ ‐ Fuse, 6.30, fast-acting, 250 V, 5 x 2 4
‐ ‐ ‐ ‐ ‐ ‐ Cover, fuse, 5 x 20 mm 4
NOTE A: Refer to Table 6-4 for fuse types and locations.
Basic Spare Parts
Part Description Quantity
1028332
Kit, basic spare parts, P4/P7/P10
—
1028305 Filter, Saturn, melter, 100-mesh 1
1028320 Kit, service, RTD, P4/P7/P10 1
1028321 Kit, service, thermostat, melter 1
1028328 Kit, service, hose/gun module, P4/P7/P10 1
1028329 Kit, service, fuse, main circuit board, P4/P7/P10 1
1028331 Kit, service, fuse, hose/gun module, P4/P7/P10 1
Expanded Spare Parts
Part Description Quantity
1028333
Kit, basic expanded parts, P4/P7/P10
—
1028305 Filter, Saturn, melter, 100-mesh 5
1028320 Kit, service, RTD, P4/P7/P10 1
1028321 Kit, service, thermostat, melter 1
1028328 Kit, service, hose/gun module, P4/P7/P10 1
1028329 Kit, service, fuse, main circuit board, P4/P7/P10 1
1028331 Kit, service, fuse, hose/gun module, P4/P7/P10 1
1028304 Kit, service, pump, P4/P7/P10 1
1028309 Kit, service, manifold, P4/P7/P10 1
1023267 Filter assembly, air, 6 mm BSPP 1
Level Switch
Used Part Description Quantity
P4, P7 1038971
Kit, switch, level, P4/P7
—
‐ ‐ ‐ ‐ ‐ ‐ Switch, level, assembly, P4/P7 1
‐ ‐ ‐ ‐ ‐ ‐ Nut, hex, M5 2
P10 1038972
Kit, switch, level, P10
—
‐ ‐ ‐ ‐ ‐ ‐ Switch, level, assembly, P10 1
‐ ‐ ‐ ‐ ‐ ‐ Nut, hex, M5 2
