Installation
3-45
Part 1024496_06
2014 Nordson Corporation
1234 567
TB2
Figure 3‐10 Wiring outputs
To set up an output
Set up the parameter control option for each output that you connected to the
melter. Table 3‐9 lists the available control options. Refer to Setting Up the
Melter earlier in this section for information about how to select operating
parameters and edit parameter control options.
The output capacity of the melter may
be increased from three outputs to
seven outputs by adding an optional
I/O expansion card that is available
from Nordson Corporation.
Section 7, Parts
